Selecting On-Bright AC/DC Power ICs: PWM Controllers, LED Drivers & Fast Charge
On-Bright focuses on offline (AC/DC) power ICs. This article explains the roles of PWM controllers, LED drivers, and USB-PD fast-charge controllers, mapped to the OB2263, OB3350, and OB2632Q.
The heart of an offline supply: the PWM controller
Wall-plug offline (AC/DC) supplies — chargers, adapters, power supplies — mostly use a flyback architecture whose heart is the PWM controller: it modulates the switch duty cycle to control energy transfer, regulate the output, and provide protection.
When choosing a PWM controller, common considerations include control mode (current-mode is common), standby power, protections (OVP/OCP/OTP), and external component count.
PWM controllers and USB-PD fast charge
On-Bright's OB2263 is a current-mode PWM controller for general offline flyback supplies; the OB2632Q is a quasi-resonant (QR) USB-PD fast-charge controller for applications such as phone/laptop fast charging that need a protocol and high efficiency.
A general 5V charger or small supply can use the OB2263; to build USB Power Delivery fast charging, choose a controller that integrates the fast-charge protocol like the OB2632Q.
LED drivers
LEDs need a stable current rather than voltage, so an LED driver IC is about constant-current control and dimming. On-Bright's OB3350 is an LED backlight/driver IC, commonly used in display backlights and general LED-lighting drive stages.
When choosing an LED driver, watch the output-current range, dimming method (PWM/analog), efficiency, and protections.
Sourcing
JLink Technology distributes On-Bright power ICs, supplying the OB2263 PWM controller, OB3350 LED driver, and OB2632Q USB-PD fast-charge controller, plus MCU products like the OB90R64A2.
If you are designing a charger, power supply, LED lighting, or fast-charge solution, send us your requirements — we will help with selection and reply with stock, pricing, and lead time.
Products mentioned
OB2263 Current-Mode PWM Controller
The OB2263 is a current-mode PWM controller for offline flyback power supplies, ideal for chargers and adapters under 30W. The switching frequency is set by an external resistor, with comprehensive protections, EMI frequency-shuffling, and low standby power.
OB3350 LED Backlight Driver IC
The OB3350 is a current-mode boost LED backlight driver providing stable constant-current drive for LCD monitor and TV backlighting. Fixed-frequency control with external PWM dimming and multiple built-in protections.
OB2632Q Quasi-Resonant Multi-Mode PWM Controller
The OB2632Q is a quasi-resonant (QR) multi-mode PWM controller designed for USB-PD fast-charge adapters, with a wide supply range covering the PD output voltage sweep. It automatically switches QR / PFM / CCM modes by load for efficiency and low EMI.
